降膜蒸发器

⽔分蒸发量Kg /h
Water evaporating capacityKg /h

1200-4000

3600-15000

8000-50000

10000-65000

进料浓度%
Feed Material Density%

根据客⼾的物料来定 According to material

出料浓度%
Discharge MaterialDensity%

根据客⼾的物料来定According to material

蒸汽压⼒Mpa
Steam pressure Mpa

0.5~0.8

蒸汽耗量Kg /kg蒸发量（带热压泵）
Steam consumptionKg /kg evaporation amount(with heat pressure pump)

0.38

0.28

0.23

0.19

蒸发温度℃
Evaporating temperature℃

45~90

杀菌温度℃
Sterilizing temperature℃

90~110

冷却⽔耗量T/T蒸发量
（进⽔20℃，出⽔40℃）
Cooling water costT/T evaporation amount
(Inputtingwater20℃,outputting water40℃)

11

8

7

6
